The Technical Edge
Double-Hull & Double-Bottom: Compliant with the latest international maritime environmental regulations to prevent spillage in case of collision.
Advanced Cargo Handling: Equipped with high-efficiency deep-well pumps and independent piping systems to prevent cross-contamination.
Shallow Draft Optimization: Specially designed for seasonal water level changes in rivers, ensuring year-round operational uptime.
Intelligent Monitoring: Real-time tank pressure, temperature, and gas leak detection sensors integrated into a centralized bridge console.
Explosion-Proof Engineering: All electrical systems and deck machinery meet strict EX-certified standards for hazardous zones.
Data-Driven Trust
Feature | Technical Specification |
Vessel Type | Inland Oil / Chemical Tanker (Type II/III) |
Deadweight Tonnage (DWT) | 1,000 – 5,000 Tons (Customizable) |
Cargo Tank Material | Marine Grade Carbon Steel / Stainless Steel 316L |
Hull Structure | Double-Hull / Double-Bottom |
Propulsion | Dual Engine Diesel / LNG Hybrid Option |
Discharge Rate | 300 – 800 m³/h (Depending on Pump Spec) |
Classification | CCS / ZC / BV / ADNR Standards |
(Safety & Compliance)
Safety is the cornerstone of liquid cargo logistics. Our tankers feature:
Inert Gas Systems (IGS): To maintain non-flammable atmospheres within cargo tanks.
Vapor Recovery Systems: Reducing VOC emissions during loading and unloading for environmental compliance.
Firefighting Systems: High-expansion foam and CO2 suppression systems covering the entire deck and engine room.
