Hydrographic & oceanographic survey ready: ADCP, multibeam sonar, side scan sonar
Dedicated wet & dry laboratories for sample processing and data analysis
Large working deck for equipment installation and scientific missions
Low-noise and vibration-controlled design for accurate data collection
Dynamic positioning system (DP1/DP2) optional
ROV/AUV handling capability with launch and recovery systems
360° navigation bridge with full research monitoring
Long endurance for offshore & deep-sea missions
Customizable cranes, winches, A-frame, davits
Comfortable accommodation for research teams and crew
Complies with international research vessel standards
Oceanographic research
Environmental monitoring
Hydrographic & bathymetric survey
Marine ecosystem & fisheries assessment
Seabed mapping & sediment sampling
Offshore wind farm survey
Meteorological & climate observation
ROV/AUV deployment & recovery
Coastal and deep-sea scientific exploration
University & government marine research programs
| Item | Specification |
|---|---|
| Length Overall (LOA) | 25–80 m (custom options) |
| Beam | 7–16 m |
| Draft | 2.5–5.5 m |
| Displacement | Custom |
| Endurance | 10–40 days |
| Speed | 10–15 knots |
| Propulsion | Diesel / Hybrid / Electric |
| DP System | DP1 / DP2 optional |
| Survey Equipment | Multibeam, Side Scan, ADCP, USBL |
| Deck Crane | 2–20 tons |
| A-Frame / Winches | Custom scientific winches |
| Navigation | Radar, GPS, AIS, ECDIS |
| Accommodation | 15–60 persons |
| Classification | CCS |
